Säljes för kunds räkning!
inkl org emb.
A Reference Class Preamp
To meet the requirement of customers who want to eliminate extra components in their system, a high-end preamp capable of driving the power amplifier directly is an essential part of the design. The DAC-9SE includes features borrowed from traditional high-end preamps:
Analog volume control design using a low noise and low distortion resistance ladder circuit similar to switch-resistor network.
Individually adjustable volume on each input for precise source level matching.
Volume adjustment in 99 precise, 0.5dB increments.
The Heart
As the heart of an audio system, the DAC-9SE supports an extensive number of inputs and formats. Utilizing one of the world’s best performing 32-bit audio DACs, the AK4493, EQ is only a first step for designing the ultimate DAC. State-of-the-art solutions, readily available to all vendors, along with the experience and proprietary know-how in creating many Editor’s Choice and Product of TheYear award-winning products elevate the NuPrime DAC-9SE well above the competition.
Inputs:
1 x USB PCM/DSD Digital (PCM up to 384kHz & DSD up to DSD256)
1 x Coaxial Digital S/PDIF (PCM up to 768KHz supporting DoP format DSD256)
1 x Optical Digital S/PDIF (PCM up to 192KHz supporting DoP format DSD64)
1 x Bluetooth or WiFi receiver module (optional)
1 x IIS/DSD HDMI connector (PCM 768KHz/32Bit and DSD 256 data streams)
1 x Analog Stereo RCA
Outputs:
1 pair of stereo RCA out: 4Vrms
1 x pair of stereo XLR balanced out: 8 Vrms
1 x Optical S/DPIF out (PCM up to 192KHz supporting DoP format DSD64)
Frequency response: 20 Hz – 20 KHz / ±0.3 dB
SNR: > 110 dB
THD+N: < 0.0005%
Dimensions: 235 mm W x 281 mm D x 55 mm H (including feet)
Weight: 2.5Kg
Worldwide AC voltage: (90VAC~130VAC // 210VAC~ 250VAC) with voltage select switch
AC Fuse: Slow-blow, 2.5A, 250VA
