Fyne Audio Classic Gold VIII SP
Innehållet kan inte visas
En perfekt kombination av klassiska högtalare som påminner om Hi-Fi-ljudets dagar och avancerad akustisk teknik. Den helt nya Vintage Classic-serien från Fyne Audio tar Fynes Vintage-koncept till en bredare publik.
Fyne Audio Vintage Classic VIII SP är en premium 2-vägshögtalare som kombinerar tidlös retrodesign med avancerad ljudteknik. Med Fynes välkända IsoFlare™-punktkällelement levererar den exakt stereobild och en naturlig, uppslukande ljudupplevelse, även utanför axeln. Den 200 mm (8 tum) bas-/mellanregisterkonen i flera fibrer, i kombination med en 25 mm magnesiumdiskant, säkerställer ett rikt och detaljerat ljud från 30 Hz till 34 kHz. Förstärkt av BassTrax™ Tractrix-diffusorn för djup, kontrollerad bas, ger det handgjorda kabinettet i björkplywood med äkta träfaner både elegans och akustisk integritet, vilket gör Classic VIII SP till en perfekt blandning av stil och prestanda.
Fyne Audios Vintage Classic Gold SP-serie tar retroinspirerade högtalare till nästa nivå och blandar tidlös design med avancerad ljudteknik. Gold SP överbryggar klyftan mellan den eleganta, vintage-estetiken hos Classic-serien och den banbrytande prestandan hos flaggskeppet Vintage-serien, och erbjuder en perfekt blandning av stil och substans.
Gold SP, tillverkad i Fynes fabrik i Glasgow, behåller den ikoniska rektangulära kabinettformen men förstärker den med högdensitetskonstruktion av björkplywood och uppgraderade IsoFlare-element, nu med en neodymdiskant för mer precist ljud. Med ett förfinat BassTrax 360-graders portningssystem kan du förvänta dig djupare, mer artikulerad bas som höjer din lyssningsupplevelse.
Vintage Classic Gold SP-serien är designad för att fånga essensen av Hi-Fi:s guldålder och är kulmen på Dr. Paul Mills livslånga passion för musik och ljudinnovation. Hans signaturberoende finns i varje detalj, vilket säkerställer att varje högtalare är lika mycket ett konstverk som ett tekniskt mästerverk.
Gold SP finns i 8-, 10-, 12- och 15-tums IsoFlare-versioner och levererar premiumprestanda med uppgraderade delningsfiltren, intern kablage och guldpläterade ETI-terminaler. Upplev ljud som aldrig förr, med en design som anspelar på det förflutna men omfamnar framtiden för Hi-Fi-ljud.
System Type
2 way, downwards firing port, twin cavity, BassTrax™ Tractrix diffuser
Recommended amplifier power (Watt RMS)
30 - 200
Continuous power handling (Watt RMS)
100
Sensitivity (2.83 Volt @ 1m)
91dB
Nominal impedance
8 Ohm
Frequency response (-6dB typical in room)
30Hz - 34kHz
Drive unit complement
1 x 200mm IsoFlare point source driver, multi-fibre bass / midrange cone, FyneFlute surround with 25mm magnesium dome compression tweeter, ferrite magnet system.
Crossover frequency
1.8kHz
Crossover type
Bi-wired passive low loss, 2nd order low pass, 1st order high pass, Full Cryo Treatment
System adjustments
High frequency energy (1.8kHz – 34kHz) +/- 3dB, Presence (2.5kHz - 5.0kHz) +/- 3dB
Dimensions - HxWxD
873 x 380 x 300mm
Net Weight - Each 26.3kg
Finishes
Walnut
Cabinet Construction
High density birch ply with extensive internal bracing
IsoFlare Point Source Driver
The Fyne Audio Vintage Classic Gold SP Series features an advanced IsoFlare™ point source driver, designed for exceptional stereo imaging and sound clarity. In this system, the bass and midrange driver share a common centre with the high-frequency unit, ensuring consistent sound dispersion even off-axis. This design allows for a more immersive listening experience by radiating sound isotropically, providing a constant directivity pattern that follows the flare of the driver cone.
The Gold SP models are equipped with upgraded IsoFlare drivers, featuring neodymium magnets and a titanium alloy compression tweeter for the larger 10, 12, and 15-inch versions, while the 8-inch model uses a magnesium dome. These enhancements reduce distortion, extend frequency response, and deliver a smooth, natural performance. The FyneFlute™ surround further improves the driver’s ability to eliminate mis-termination effects and reduces colouration, ensuring precise bass and midrange clarity. This meticulous driver design is the core of the Vintage Classic Gold SP Series, offering a fusion of retro aesthetic and state-of-the-art acoustic performance.
BassTrax Tractrix Diffuser System
The BassTrax Tractrix diffuser system in the Fyne Audio Vintage Classic Gold SP series is designed to deliver precise and uniform bass performance. This system utilises a downward-firing port with a twin-cavity reflex loading arrangement. Hidden beneath the grille cloth at the base of the loudspeaker, this innovative diffuser converts the downward-directed energy into a 360-degree wavefront, dispersing sound evenly across the room.
Inspired by the Tractrix geometry, the BassTrax profile maintains a consistent 90-degree angle at every intersection, minimising reflections and ensuring smooth, distortion-free bass reproduction. This clever design not only enhances bass articulation but also makes the loudspeaker less sensitive to room placement, allowing for flexible positioning without compromising sound quality.
By reducing standing waves and internal reflections, the BassTrax system ensures tighter, more controlled low-frequency performance, contributing to the Vintage Classic Gold SP Series’ ability to deliver deep, immersive bass while maintaining clarity across all frequencies .
Crossover
The Vintage Classic Gold SP Series is equipped with an expertly designed, bi-wired passive crossover, fine-tuned for exceptional audio clarity. Using premium audiophile components, including high-grade polypropylene capacitors, low-loss laminated iron core inductors, and high-power precision resistors, the crossover is engineered to deliver a natural and transparent sound.
Each component is hand-wired on fibreboard panels to reduce vibration, while the entire assembly undergoes Deep Cryogenic Treatment (DCT) to improve the signal path which can become affected during the manufacturing process. This meticulous attention to detail ensures optimal signal transfer and precise frequency separation between the bass/midrange and high-frequency drivers.
The inclusion of upgraded gold-plated ETI terminals and Neotech PC-OCC wiring allows for superior conductivity and signal integrity, bringing out the best in every listening session.
In addition to premium components, the Gold SP series offers adjustable controls for High Frequency (HF) Energy and Presence, allowing you to fine-tune the sound to match your room acoustics and personal preferences. Together, these components deliver a seamless, dynamic soundstage that highlights the Vintage Classic Gold SP's signature balance of high-fidelity performance and retro-inspired design .
VINTAGE CLASSIC CABINETS
The Vintage Classic Gold SP Series cabinets are crafted from high-density birch ply, chosen for its strength and low resonance properties. Internally braced for added rigidity, the precisely manufactured cabinet minimises unwanted vibrations, ensuring a cleaner, more accurate sound.
Aesthetically, the Gold SP Series retains the timeless rectangular cabinet shape with a luxurious walnut veneer finish, accented by gold-anodized metalwork. This fusion of retro-inspired design and modern craftsmanship creates a stunning visual presence while staying true to the golden age of Hi-Fi. The robust structure not only contributes to a more refined sound but also adds a touch of elegance to any listening space, making it both a performance and style statement .
